Strain controllable band alignment and the interfacial and optical properties of tellurene/GaAs van der Waals heterostructures

Abstract

By using first principles calculations, we theoretically investigate the electronic structures and the interfacial and optical properties of the two-dimensional tellurene (Te)–gallium arsenide (GaAs) van der Waals heterostructures (vdWHs), i.e., α-Te/GaAs and γ-Te/GaAs, formed using Te and GaAs monolayers. It has been demonstrated that, the semiconductor–semiconductor contacted α-Te/GaAs vdWH exhibits a type-II band alignment with a direct band gap of 0.28 eV while the metal–semiconductor contacted γ-Te/GaAs vdWH has a p-type Schottky contact with a Schottky barrier height (SBH) of 0.36 eV at the interface. The transition from type-II to type-III band alignment is observed firstly in the α-Te/GaAs vdWH when the in-plane biaxial strain is less than −5.2% and larger than 4.4%, meanwhile, the p-type Schottky contact to Ohmic contact transition may be realized in the γ-Te/GaAs vdWH when the in-plane biaxial strain is less than −2.4%. Finally, the maximum optical absorption coefficients of the α- and γ-Te/GaAs vdWHs have been found to be up to 31% and 29%, respectively, and may be modulated effectively by applying in-plane biaxial strain. The obtained results may be of importance in the design of nanoelectronic devices based on the proposed tellurene/GaAs vdWHs.
